InBiSe₃ Crystals

Price range: £499.99 through £899.99

Select an option to request a quote

Flat rate shipping £15

    InBiSe₃ Crystals

    InBiSe₃ is a layered ternary chalcogenide material with a van der Waals structure, exhibiting unique electronic, optical, and thermal properties. With a tunable bandgap and strong anisotropic behavior, InBiSe₃ is a promising candidate for applications in optoelectronics, energy storage, and advanced 2D material research.

    Sample Size Options:
    Crystals larger than 10 mm²
    Crystals larger than 25 mm²
    Crystals larger than 100 mm²

    Material Properties:
    Layered van der Waals Structure: Enables exfoliation into thin layers for 2D research.
    Tunable Bandgap: Suitable for visible and infrared optoelectronic applications.
    Anisotropic Properties: Strong direction-dependent electronic and optical characteristics. Thermal and Chemical Stability: Maintains performance under controlled conditions.

    Crystal Structure:
    Type: Layered rhombohedral structure
    Features: Cleavable layers ideal for nanoscale applications and heterostructures.

    Degree of Exfoliation:
    Ease of Use: Easily exfoliates into monolayers or few-layer sheets for advanced applications.

    Other Characteristics:
    Optoelectronic Properties: High optical absorption and quantum efficiency for photonic devices.
    Semiconducting Behavior: Promising for nanoscale electronic and optoelectronic research.
    Environmental Stability: Stable under inert storage and controlled environments.

    Applications:
    Optoelectronics:
    Ideal for photodetectors, infrared light sensors, and light-emitting devices. Energy

    Applications:
    Suitable for photocatalysis and energy storage devices due to its strong optical absorption.
    2D Material Studies:
    Excellent for exploring exfoliated layers and van der Waals heterostructures. Quantum Materials Research:
    Enables studies of low-dimensional electronic and optical phenomena. Sensors:
    High sensitivity to environmental stimuli, making it suitable for advanced sensing applications.

    Option 1

    > 10 mm², > 100 mm², > 25 mm²
