Zirconium Carbide (ZrC) Evaporation Pellets, 99.5% Purity (Request Current Price)
Price upon request
For research and laboratory use only. Not for medical, diagnostic or household use.
Zirconium Carbide (ZrC) Evaporation Pellets, 99.5% Purity (Request Current Price)
Nanostore Zirconium Carbide (ZrC) evaporation pellets are high-purity compound source materials supplied for evaporation coating, thin-film deposition research, optical and functional films, and laboratory PVD process development. The pellet format is used for weighing, source loading, and small-batch experimental workflows where clean handling and controlled material identity are important. Pricing requires a current quote because compound evaporation materials can vary with purity, package size, and current material availability.
Key Features
High-Purity Compound Evaporation Material
Available purity options include 99.5% (2N5) for research workflows that require controlled compound composition.
Pellet Format for Source Loading
Available particle-size options include 0.0394 in-0.394 in (1-10 mm) pieces. Package options include 1 kg, 100 g, 500 g depending on selected purity and configuration.
Compound Material Selection
This material is a refractory ceramic carbide supplied as evaporation pellets for thin-film deposition and coating research.
Technical Specifications
Material: Zirconium Carbide (ZrC)
Form: Evaporation Pellets
Purity Options: 99.5% (2N5)
Available Size Options: 0.0394 in-0.394 in (1-10 mm) pieces
Package Options: 1 kg, 100 g, 500 g
Category: Evaporation Materials
Typical Use: Evaporation source material, PVD research, optical coating, and laboratory materials science
Material Handling and Quality Notes
– Packaging and storage: keep sealed, dry, and protected from contamination; handle with clean gloves or tools before loading.
Quality-Control and Handling Indicators
– Analytical checks: ICP-MS trace-element analysis; ICP impurity/composition analysis; GDMS trace-metal analysis; carbon/sulfur impurity analysis; nitrogen/oxygen impurity analysis; chemical composition analysis.
– Inspection focus: particle-size screening; appearance inspection; dimensional verification.
– Handling and storage: sealed dry storage and protective packaging; clean-glove handling to avoid oil, dust, moisture, and surface contamination; careful handling to prevent compression, impact, or chipping.
– Deposition-use context: magnetron sputtering systems; ion sputtering systems; micro/nano fabrication research; semiconductor thin-film development; photovoltaic materials research; flat-panel display coating research.
Common Applications
– zirconium carbide evaporation source loading
– ultra-high-temperature ceramic coating research
– wear-resistant and protective carbide film studies
– laboratory ZrC deposition workflows
– Academic, industrial, and pilot-scale thin-film materials research
Specifications
| Material | Zirconium Carbide (ZrC) |
|---|---|
| Chemical formula | ZrC |
| Purity options | 99.5% (2N5) |
| Form | Evaporation Pellets |
| Available sizes | 0.0394 in-0.394 in (1-10 mm) pieces |
Typical properties of the bulk material (literature values)
| CAS number | 12070-14-3 |
|---|---|
| Molar mass | 103.23 g/mol |
| Density | 6.73 g/cm³ |
| Melting point | 3540 °C |
Sources: PubChem (U.S. National Library of Medicine), NIST (National Institute of Standards and Technology) and published reference data (handbooks and supplier data sheets). Reference values for the bulk substance, not test results of a specific lot.
| Option 1 | 99.5% (2N5) |
|---|---|
| Option 2 | 0.0394 in-0.394 in (1-10 mm) pieces |
| Option 3 | 1 kg, 100 g, 500 g |
