An L-shape electrode holder that clamps thin sheet or foil samples for use as working electrodes in a three-electrode cell. The platinum contact carries current to the sample while the PEEK body isolates the connection from the electrolyte.
Key Features
- Platinum contact part for a clean electrical connection to the sample
- PEEK insulation for chemical resistance across common electrolytes
- L-shape geometry for mounting planar electrodes over the cell
Specifications
| Contact part | Platinum |
| Insulation materials | PEEK |
| Operating Temperature Range | Room Temperature – 65°C |
| Clamping Thickness | 0.1-3mm |
Suited to voltammetry and electrolysis work where a flat metal, semiconductor, or coated substrate must be held as the working electrode in aqueous or organic media.
