GeBi₄Te₇ Crystals

Price range: £499.99 through £569.99

Select an option to request a quote

Flat rate shipping £15

    GeBi₄Te₇ Crystals

    GeBi₄Te₇ is a layered chalcogenide material with a van der Waals structure, known for its high thermoelectric, electronic, and optical properties. It is a promising candidate for energy conversion, quantum materials research, and spintronic applications due to its high thermoelectric efficiency, robust surface states, and strong spin-orbit coupling. Our GeBi₄Te₇ crystals are synthesized using the Chemical Vapor Transport (CVT) method, ensuring high purity, precise stoichiometry, and high crystallinity.

    Sample Size Options:
    Crystals larger than 10 mm²
    Crystals larger than 25 mm²

    Material Properties:
    Layered van der Waals Structure: Facilitates exfoliation into thin layers for 2D material studies.
    Thermoelectric Efficiency: High Seebeck coefficient and low thermal conductivity for energy applications.
    Topological Insulator Behavior: Exhibits robust surface states with spin-momentum locking.
    Optical Absorption: Strong absorption in the visible and infrared ranges, suitable for photonic devices.

    Crystal Structure:
    Type: Rhombohedral layered structure
    Features: Cleavable layers ideal for thin-film fabrication and nanoscale research.

    Degree of Exfoliation:
    Ease of Use: Readily exfoliates into monolayers or few-layer sheets for advanced research applications.

    Other Characteristics:
    Quantum Properties: Promising for studying topological surface states and quantum transport phenomena. Energy

    Applications: Suitable for energy harvesting and thermal management systems. Spintronics

    Applications: Ideal for exploring spin-based devices and spin-orbit coupling.

    Applications:
    Quantum Materials Research:
    Enables studies of topological insulators and associated quantum phenomena. Thermoelectric Devices:
    Ideal for energy conversion and cooling technologies. Spintronics:
    Promising for spin-based devices and exploring spin-related phenomena.
    2D Material Studies:
    Perfect for exfoliation into thin layers and integration into van der Waals heterostructures. Optoelectronics:
    Suitable for photodetectors, sensors, and other optoelectronic devices.

    Option 1

    > 10 mm², > 25 mm²
