Ag/AgCl Reference Electrode, Ø4 mm Glass Body
£104.99
Dispatch normally within 1 business day; carrier transit normally 6–8 business days (7–9 business days in total). See Shipping Policy and Returns Policy.
For research and laboratory use only. Not for medical, diagnostic or household use.
Ag/AgCl reference electrode for general aqueous (neutral) electrochemical measurements such as voltammetry and potentiometry. A gold-plated pin connects the electrode to the potentiostat lead, and the end of the glass tube carries a black protective cap.
Specifications: connector pin, gold-plated, 16 mm long; white PTFE section, Ø6 mm × 26 mm; glass tube, Ø4 mm × 46 mm, with a black protective cap at the tip. Supplied as a single electrode. Dimensions are nominal; the electrodes are assembled by hand, so small deviations are normal.
Use and storage: Ag/AgCl references are typically used with a chloride electrolyte such as saturated or 3 M KCl; check that the filling suits your cell and working geometry before use. After use, rinse the tip with deionised water and store the electrode in a closed container, away from light, with the tip kept wet rather than allowed to dry out. The glass tube is thin; handle it with care.
