Non-Aqueous Ag/Ag+ Reference Electrode, Ø4 mm Glass Body
£104.99
Dispatch normally within 1 business day; carrier transit normally 6–8 business days (7–9 business days in total). See Shipping Policy and Returns Policy.
For research and laboratory use only. Not for medical, diagnostic or household use.
Ag/Ag+ reference electrode for voltammetry and other electrochemical measurements in organic (non-aqueous) electrolytes. A non-aqueous reference keeps water out of the cell. The glass tube ends in a porous frit junction, and a gold-plated pin connects the electrode to the potentiostat lead.
Specifications: connector pin, gold-plated, 20 mm long; white PTFE section, Ø6 mm × 27 mm; glass tube, Ø4 mm × 45 mm, with a porous frit junction at the tip. Supplied as a single electrode. Dimensions are nominal; the electrodes are assembled by hand, so small deviations are normal.
Use and storage: a non-aqueous Ag/Ag+ electrode is typically filled with a silver salt solution, for example about 0.01 M AgNO₃ in the solvent of the experiment (such as acetonitrile) together with the supporting electrolyte; check the filling and its compatibility with your solvent before use. After use, rinse the tip with the solvent and store the electrode upright in the same solution in a closed container, away from light, so that the junction does not dry out. The glass tube is thin; handle it with care.
In an Ag/Ag+ reference system, the reference potential is governed by equilibrium between metallic silver and dissolved silver ions. It provides a separate reference against which the working electrode potential is controlled or reported. The reference electrode has a different role from the counter electrode, which carries the main cell current.
Non-aqueous reference electrodes are commonly used in redox chemistry, molecular electrochemistry and energy-storage research. The solvent environment and silver-ion activity influence the reference potential, so potentials reported against different reference systems require context when compared.
