Bi₄Pb₇Se₁₃ Crystals

Price range: £499.99 through £1,299.99

Select an option to request a quote

Flat rate shipping £15

    Bi₄Pb₇Se₁₃ Crystals

    Bi₄Pb₇Se₁₃ is a layered thermoelectric material with a van der Waals structure, combining strong electronic, optical, and thermoelectric properties. Its high thermoelectric efficiency, strong spin-orbit coupling, and structural stability make it a promising material for quantum materials research, energy harvesting, and spintronics. Our Bi₄Pb₇Se₁₃ crystals are synthesized using the Chemical Vapor Transport (CVT) method, ensuring high purity, precise stoichiometry, and superior crystallinity.

    Sample Size Options:
    Crystals larger than 10 mm²
    Crystals larger than 25 mm²
    Crystals larger than 100 mm²

    Material Properties:
    Layered van der Waals Structure: Facilitates exfoliation into thin layers for 2D material studies.
    Thermoelectric Efficiency: High Seebeck coefficient and low thermal conductivity for energy harvesting applications.
    Electronic Conductivity: Excellent carrier mobility for electronic and thermoelectric devices.
    Optical Absorption: Strong absorption in the visible-to-infrared range, ideal for photonic devices.

    Crystal Structure:
    Type: Rhombohedral layered structure
    Features: Cleavable layers, suitable for thin-film fabrication and nanoscale device integration.

    Degree of Exfoliation:
    Ease of Use: Readily exfoliates into monolayers or few-layer sheets for advanced research.

    Other Characteristics:
    Quantum Properties: Promising for studying topological surface states and quantum transport phenomena. Thermoelectric

    Applications: Ideal for energy harvesting and thermal management systems. Spintronics

    Applications: Suitable for exploring spin-based devices and spin-orbit coupling.

    Applications:
    Quantum Materials Research:
    Enables exploration of topological insulators and associated quantum phenomena. Thermoelectric Devices:
    Promising for energy conversion and cooling technologies. Spintronics:
    Ideal for spin-based devices and spintronic memory technologies.
    2D Material Studies:
    Perfect for exfoliation into thin layers and integration into van der Waals heterostructures. Optoelectronics:
    Suitable for photodetectors, sensors, and other optoelectronic devices.

    Option 1

    > 10 mm², > 100 mm², > 25 mm²
