Aluminum Copper Alloy (AlCu) Pellets And Pieces, 99.9%-99.999% Purity (Request Current Price)

Aluminum Copper Alloy (AlCu) Pellets And Pieces, 99.9%-99.999% Purity (Request Current Price)

Nanostore Aluminum Copper Alloy (AlCu) pellets and pieces are high-purity alloy source materials supplied for thin-film deposition research, evaporation source loading, custom alloy preparation, and laboratory materials development. The pellet and piece formats are convenient for weighing, loading, and small-batch experimental workflows where material identity, purity selection, and clean handling are important. Pricing requires a current quote because high-purity metal costs vary with purity, package size, and material market conditions.

Key Features

High-Purity Elemental Source Material
Available purity options include 99.999% (5N), 99.9% (3N), 99.95% (3N5), 99.99% (4N) for research workflows that require controlled metal composition.

Pellet and Piece Formats
Available particle or piece sizes include 0.236 in x 0.236 in dia/length (6 x 6 mm) cylindrical pellets, Custom specification, 0.0394 in-0.787 in (1-20 mm) pieces, 1.18 in-1.97 in (30-50 mm) pieces, 0.394 in-1.18 in (10-30 mm) pieces, 0.0394 in-0.394 in (1-10 mm) pieces. Package options include 1 kg depending on selected purity and size.

Clean Handling and Storage
Store sealed in a dry environment. Handle with clean gloves or tweezers and avoid contact with oils, dust, moisture, or other contaminants before use.

Technical Specifications

Material: Aluminum Copper Alloy (AlCu)
Form: Pellets And Pieces
Purity Options: 99.999% (5N), 99.9% (3N), 99.95% (3N5), 99.99% (4N)
Available Size Options: 0.236 in x 0.236 in dia/length (6 x 6 mm) cylindrical pellets, Custom specification, 0.0394 in-0.787 in (1-20 mm) pieces, 1.18 in-1.97 in (30-50 mm) pieces, 0.394 in-1.18 in (10-30 mm) pieces, 0.0394 in-0.394 in (1-10 mm) pieces
Package Options: 1 kg
Category: Metal Pellets & Pieces
Typical Use: Evaporation source material, PVD research, alloy preparation, and laboratory materials science

Material Properties and Technical Indicators

Reference material-property values for selection, evaporation planning, and process evaluation:

– Formula / alloy system: AlCu
– Nominal composition: Al:Cu = 98:2 wt%, 10:90 at%, 96:4 wt%, 50:50 wt%, 99.5:0.5 wt%, 30:70 at%, or 90:10 at%

Quality-Control and Handling Indicators

Additional technical indicators reflected from the source product page:

– Analytical checks: ICP impurity/composition analysis.
– Inspection focus: dimensional verification.

Common Applications

– Al-Cu alloy evaporation source loading
– aluminum copper metallization and alloy-film research
– custom aluminum alloy source preparation
– laboratory PVD materials development
– Academic, industrial, and pilot-scale materials research
