Magnesium Oxide (MgO) Single Crystal Substrates
MgO

Magnesium Oxide (MgO) Single Crystal Substrates

Price range: $27.83 through $98.83

Select an option to request a quote

Magnesium Oxide (MgO) Single Crystal Substrate

Physical Properties:
– Crystal Structure: Cubic System
– Lattice Constant: a = 4.216 Angstrom
– Density: 3.58 g/cm³
– Melting Point: 2852 °C
– Mohs Hardness: 5.5
– Growth Method: Arc Fusion

Standard Specifications:
– Orientation Accuracy: (100) < 0.3°; (110)/(111) < 0.5°
– Surface Roughness: Ra < 0.5 nm
– Edge Orientation: Available upon request
– Surface Polish: Single-Side or Double-Side Polished

Option 1

10 × 10 × 0.1 mm, (100), Double-Side Polished, 10 × 10 × 0.5 mm, (100), Double-Side Polished, 10 × 10 × 0.5 mm, (100), Single-Side Polished, 10 × 10 × 0.5 mm, (110), Double-Side Polished, 10 × 10 × 0.5 mm, (110), Single-Side Polished, 10 × 10 × 0.5 mm, (111), Double-Side Polished, 10 × 10 × 0.5 mm, (111), Single-Side Polished, 20 × 5 × 2 mm, (001), Double-Side Polished, 5 × 5 × 0.5 mm, (100), Double-Side Polished, 5 × 5 × 0.5 mm, (100), Single-Side Polished, 5 × 5 × 0.5 mm, (110), Double-Side Polished, 5 × 5 × 0.5 mm, (110), Single-Side Polished, 5 × 5 × 0.5 mm, (111), Double-Side Polished, 5 × 5 × 0.5 mm, (111), Single-Side Polished
