Strontium Lanthanum Gallate (SrLaGaO₄) Single Crystal Substrate
Price range: $600.03 through $722.55
Strontium Lanthanum Gallate (SrLaGaO₄) Single Crystal Substrate
Physical Properties:
– Crystal Structure: Tetragonal System
– Lattice Constants: a=3.843Angstrom , c=12.680Angstrom
– Melting Point: 1500 °C
– Density: 6.389 g/cm³
– Growth Method: Czochralski (CZ)
Standard Specifications:
1. Orientation
– (001) miscut < 0.3°
– (100) miscut < 0.3°
2. Edge Orientation
– Available
3. Surface Quality
– Surface Roughness: Ra: < 0.5 nm
– Polish: Single-side polished / Double-side polished
| Option 1 | 10 × 10 × 0.5 mm, (001), Double-Side Polished, 10 × 10 × 0.5 mm, (001), Single-Side Polished, 10 × 10 × 0.5 mm, (100), Double-Side Polished, 10 × 10 × 0.5 mm, (100), Single-Side Polished, 5 × 5 × 0.5 mm, (001), Double-Side Polished, 5 × 5 × 0.5 mm, (001), Single-Side Polished, 5 × 5 × 0.5 mm, (100), Double-Side Polished, 5 × 5 × 0.5 mm, (100), Single-Side Polished |
|---|
