CaNdAlO₄ Single Crystal Substrate
Physical Properties:
– Crystal Structure: Tetragonal System
– Lattice Constant: a=3.685Angstrom , c=12.12Angstrom
– Density: 5.56 g/cm³
– Melting Point: 1850 °C
– Growth Method: Czochralski Method
Standard Specifications:
– Orientation: (100) miscut < 0.3°, (001) miscut < 0.3°
– Dimensions: 5 x 5 x 0.5mm, 10 x 10 x 0.5mm
– Surface Finish: Single-Side Polished / Double-Side Polished
| Option 1 | 10 × 10 × 0.5 mm, 5 × 5 × 0.5 mm |
|---|---|
| Option 2 | Double-Side Polished, Single-Side Polished |
| Orientation | (001), (100) |
