Calcite (CaCO₃) Single Crystal Substrate
Product Overview:
Calcite (CaCO₃) is a carbonate mineral with a trigonal crystal structure. It is well-known for its high birefringence and wide transmission range, making it an essential material for polarizing prisms, beam splitters, and other optical components operating from the visible to the near-infrared spectrum.
Physical Properties:
– Material: Calcite (CaCO₃)
– Crystal Structure: Trigonal System
– Lattice Constant: a = 4.989 Angstrom, c = 17.062 Angstrom
– Density: 2.71 g/cm³
– Mohs Hardness: 3 (Mohs)
– Melting Point: 1339 °C
– Thermal Conductivity: 4.646 W/m·K for 273 K
– Transmission Range: 350 nm ~ 2300 nm
Standard Specifications:
– Orientation: (100) miscut < 0.3°, (001) miscut < 0.3°
– Dimensions: 5 mm x 5 mm, 10 mm x 10 mm
– Thickness: 0.5 mm
– Surface Finish: Single-Side Polished / Double-Side Polished
| Option 1 | 10 × 10 × 0.5 mm, (001), Double-Side Polished, 10 × 10 × 0.5 mm, (001), Single-Side Polished, 10 × 10 × 0.5 mm, (100), Double-Side Polished, 10 × 10 × 0.5 mm, (100), Single-Side Polished, 5 × 5 × 0.5 mm, (001), Double-Side Polished, 5 × 5 × 0.5 mm, (001), Single-Side Polished, 5 × 5 × 0.5 mm, (100), Double-Side Polished, 5 × 5 × 0.5 mm, (100), Single-Side Polished |
|---|
