TiO2 Single Crystal Substrates (Rutile Phase)
TiO₂

TiO₂ Single Crystal Substrates (Rutile Phase)

Price range: €92.06 through €501.01

Select an option to request a quote

Product Name:
TiO₂ (Titanium Dioxide) Single Crystal Substrates (Rutile Phase)

Packaging & Variant Options:
– Packaging: 100-class clean bag, 1000-class clean room
– Available Dimensions (Square/Rectangular):
– 5 × 3mm,5 × 5mm, 10 × 5mm, 10 × 10mm, 15 × 15mm, 20 × 20mm
– Available Dimensions (Circular):
– Φ10mm, Φ15mm, Φ20mm, Φ1″, Φ2″
– Standard Thickness (T): 0.5mm
– Polishing Status: Single-side Polished (SSP) or Double-side Polished (DSP)

Product Description:
Overview: Rutile Titanium Dioxide (TiO₂) single crystal substrates are used as substrate materials for thin-film growth and deposition. Has its high refractive index and high dielectric properties, TiO₂ is an essential material in the research of functional oxides, optical coatings, and semiconductor heterostructures.

Technical Specifications:
– Crystal System: Tetragonal
– Growth Method: Floating Zone Method / Flame Fusion (Verneuil Method)
– Lattice Constants: a = 4.594 Angstrom, c = 2.958 Angstrom
– Melting Point: 1850 °C
– Density: 4.26 g/cm³
– Hardness: 7 Mohs
– Thermal Expansion Coefficient:
– 9.19 × 10⁻⁶ / °C (Parallel to c-axis)
– 7.14 × 10⁻⁶ / °C (Perpendicular to c-axis)
– Chemical Behavior: Insoluble in water; resistant to most acids at room temperature

Option 1

10 × 10 × 0.5 mm, (001), Double-Side Polished, 10 × 10 × 0.5 mm, (001), Single-Side Polished, 10 × 10 × 0.5 mm, (100), Double-Side Polished, 10 × 10 × 0.5 mm, (100), Single-Side Polished, 10 × 10 × 0.5 mm, (110), Double-Side Polished, 10 × 10 × 0.5 mm, (110), Single-Side Polished, 10 × 10 × 0.5 mm, (111), Double-Side Polished, 10 × 10 × 0.5 mm, (111), Single-Side Polished, 15 × 15 × 0.5 mm, Double-Side Polished, 15 × 15 × 0.5 mm, Single-Side Polished, 5 × 3 × 0.5 mm, (001), Single-Side Polished, 5 × 3 × 0.5 mm, (100), Single-Side Polished, 5 × 3 × 0.5 mm, (110), Single-Side Polished, 5 × 5 × 0.5 mm, (001), Double-Side Polished, 5 × 5 × 0.5 mm, (001), Single-Side Polished, 5 × 5 × 0.5 mm, (100), Double-Side Polished, 5 × 5 × 0.5 mm, (100), Single-Side Polished, 5 × 5 × 0.5 mm, (110), Double-Side Polished, 5 × 5 × 0.5 mm, (110), Single-Side Polished, 5 × 5 × 0.5 mm, (111), Single-Side Polished
